Panorama Motherboard CMOS Setup/Verification Appendix A
7 - 4 0070-10-0634 Panorama® Service Manual
CPU-TO-PCI IDE POSTING: ENABLED
SYSTEM BIOS CACHEABLE: DISABLED
VIDEO BIOS CACHEABLE: DISABLED
VIDEO RAM CACHEABLE: DISABLED
8 BIT I/O RECOVERY TIME: 1
16BIT I/O RECOVERY TIME: 1
MEMORY HOLE AT 15M-16M: DISABLED
PASSIVE RELEASE: ENABLED
DELAYED TRANSATION: ENABLED
AGP APERATURE SIZE (MB): 64
SDRAM RAS-TO CAS DELAY: FAST
SDRAM RAS PRECHARGE TIME: FAST
SDRAM CAS LATENCY TIME: 3
AUTO DETECT DIMM/PCI CLK: ENABLED
SPREAD SPECTRUM MODULATED: 0.6% (CNTR)
CURRENT SYSTEM TEMP: CURRENT TEMPERATURE
CHASSIS FAN: 0 RPM (not applicable)
PRIMARY FAN: CURRENT SPEED
SECONDARY/POWER FAN: 0 RPM (not applicable)
IN0(V): CURRENT VOLTAGE (Typically between 2.25-2.75
Volts)
IN1(V): CURRENT VOLTAGE (Typically 2.0 Volts)
IN2(V): CURRENT VOLTAGE (Typically between 2.95-3.65
Volts)
IN3(V): CURRENT VOLTAGE (Typically between 4.75-5.25
Volts)
IN4(V): 0 volts (not applicable)
IN5(V): CURRENT VOLTAGE (Typically between -10.7 and -
13.2 Volts)
IN6(V): CURRENT VOLTAGE (Typically between -4.5 and -
5.5 Volts)
CHIPSET FEATURES SETUP (CONTINUED)
AUTO CONFIGURATION: ENABLED
