Mindray Z5 - Log Maintenance

Software Upgrade and Maintenance 6-13
6.5.2 Log Maintenance
6.5.2.1 Export the Log
1. Connect the USB disk.
2. Click [Export Log] on the Maintenance menu.
3. Select the path in the Browse page to save the log, and click [OK].
4. When the log is exported, the system prompts “Export succeed!” click [OK] to return to the
Maintenance menu.
NOTE:
The log can be exported to the external USB storage device only, make sure the
connection between U disk and ultrasound is normal before the exporting.
6.5.2.2 Log Uploading
1. Click [Upload Log] on the Maintenance menu, and select the log type in the sub-menu
2. Click [Upload] in the popping up dialogue, the system performs log uploading automatically.
After the uploading is finished, the system will prompt “Upload succeed”
