5.3 Soldering Iron Tip Maintenance
5.4 Soldering Iron Tip Lifespan
11.5
4
5
°
5.2 Choosing Soldering Iron Tips
Note: Choosing the right tips will help you to work more efficient
TS-D24TS-BC2TS-KTS-B2
10.0
10.0
15.0
4
5
°
15
5
Soldering Iron Tip
(1) Before switching off, wipe the tip’s soldering side with some solder.
(2) Do not leave the tip in high temperature for long time, which may causeit burn out.
(3) Do not push too hard while soldering, which will damage the tip.
(4) Do not use rough material or files to clean the tip.
(5) If the tip surface is oxidized and makes it hard to apply solder on it, you may use
600~800 grit sandpaper to wipe the tip with Ethanol or Isopropyl alcohol, heat
up to 200℃ and apply solder immdeiately to avoid it oxidize again.
(6) Do not use Flux that contains high chlorine or acid, use only resin based flux.
Soldering iron tips lifespan is related to its maintenance (refer to 5.3)and use intensity.
