Mini TS100 - Overview; Ports and Control Panel Introduction

2.1 Ports and Control Panel Introduction
1.The tip setscrew
4.Ground cable fixing screw
2.Button A
8.Soldering tip port
7.DC5525
12-24V port
6.Micro USB
5.Power c
onnector
1
4
2
3
8
7
6
10
9
5
2
3
Overview
3.Button B
9.Soldering tip connector
10.Solder
ing tip heating end
