SMARTBOX OPERATING MANUAL—JUNE 2009
7. Installation
Anchoring bolts
The safe must be anchored by securing
either the back or the bottom of the safe.
You may select the expansion bolt for a
concrete wall surface or select a clamping
bolt for a wooden surface.
Example of a clamping bolt
Securing the bottom of the safe
Securing the back of the safe
Safe Dimensions
Model Dimensions
H x W x D (mm)
Net weight
(kgs)
Volume
(litres)
S 200 x 350 x 220 9 10
M 200 x 435 x 383 14
22
L 254 x 483 x 400
17 34
Technical Specifications
Thickness of body
Thickness of door
Material of body, door and bolt work
Material of fixing screws
2 mm
5 mm
solid steel DIN ST37-2
solid steel DIN ST37-2
