1 PRODUCT OVERVIEW
Thank you for purchasing the miniDSP DDRC-24 audio processor powered by Dirac Live®, the world’s premier
room correction solution. We are delighted to offer you this extremely compact yet powerful software and
hardware combination, the fruit of extensive research and development and years of experience in sound
system tuning.
The miniDSP DDRC-24 offers not only a two-channel Dirac Live® room correction processor, but also an input-
output matrix mixer and a powerful set of DSP audio processing functions on each output channel. This allows
the DDRC-24 to be used for correction of a stereo signal, integration of one or two subwoofers, or to implement
a combined two-way crossover and room correction processor. Combined with its selection of analog, optical
digital, and asynchronous USB (up to 192 kHz) inputs, the miniDSP DDRC-24 offers an unprecedented level of
audio processing performance for its size and price bracket.
1.1 TYPICAL APPLICATION
In the application shown in Figure 1, the miniDSP DDRC-24 acts as preamp and room correction/subwoofer
integration processor. Volume control is accomplished with a remote control by using the DDRC-24’s remote
learning feature.
Many other system configurations are possible with the miniDSP DDRC-24. See the Plugin configuration guide
(page 23) for examples.
Figure 1 – miniDSP DDRC-24 as preamp and subwoofer integration/room correction processor
