Minuteman X17 - Machine Overview; X17 CFS Front Components; Vacuum Connection Components

10
© 2015 Minuteman International, Inc.
X17 ECO CFS Carpet Extractor #988751UM Rev. * 04/15
P
M
Q
N
Machine Overview
L
L
K
R
A
G
B
G
C
E
D
F
H
J
Vacuum Connection
K. VACUUM MOTOR INTAKE COVER
L. VACUUM CONNECTION TUBE
M. RECOVERY INLET
N. RECOVERY TANK HANDLE
P. VACUUM FLOAT SHUT-OFF
Q. RECOVERY WINDOW EXTENSION HOSE
R. VACUUM MOTOR GASKET
X17 CFS Front
A. HANDLE
B. RECOVERY DOME LID
C. RECOVERY TANK
D. SOLUTION TANK
E. SOLUTION TANK FILL PORT
F. FAUCET FILL HOSE
G. RECOVERY WINDOW
H. BRUSH MOTOR BELT COVER
J. VAC SHOE
