Minuteman X17 - Handle Assembly; Assembly

7
© 2015 Minuteman International, Inc.
X17 ECO CFS Carpet Extractor #988751UM Rev. * 04/15
A
C
B
E
D F
Handle Assembly
The X17 CFS Handle Assembly (D) is not assembled
on the machine when shipped. Follow the instruction
on the next page to connect the handle assembly to the
machine.
A HANDLE ADJUSTMENT KNOB
B SHOULDER BOLT
C COVER
D HANDLE ASSEMBLY
E SCREW
F CORD RELIEF
Assembly
