Appendix C: Specifications
PR-300 Polarity Reversal and City Tie Module
City Tie power limited / 24VDC unfiltered / 250mA max
/14Ohms trip coil
Polarity Reversal power limited / 24VDC open / 12VDC at
3.5mA / 8.5mA max (shorted)
Polarity Reversal Supv. Terminal 24VDC (normal) / -24VDC (supervisory) / 0V
(trouble)
Polarity Reversal Alarm Terminal 24VDC (normal) / -24VDC (alarm) / 0V
(trouble)
Current Consumption standby 50mA / alarm 300mA (city tie in use) /
alarm 70mA (city tie not in use)
RTI Remote Trouble Indicator Standby 35mA / alarm 35mA
Table 17 FA-300 LED System Modules and Annunciators (Continued)
FA-300 LED Series Modules and Annunciators
