78
Operation
1
1.6.3
Evacuation Codes
Single st
age codes
T
w
o-st
age codes:
Figure 47 Evacuation Codes
Continuous
On 100% of the time
T
emporal Code
3 of
0.5 second on, 0.5 seco
nd off then, 1.5 second p
ause
March Code
0.5 second on, 0.5 second
off
California Code
5 seco
nds on, 10 seco
nds off
Alert Code
0.5 se
cond on, 2.5 seconds of
f
General Alarm
Evacuation code
as s
elected from above.
0.5s
5
s
10s
0.5s
1.5s
Continuous
T
emporal C
ode
March Code
Calif
ornia Code
Aler
t Code
0.5s
0.5s
0.5s
2.5s
80
