RA-1000 Remote Annunciator Wiring and Instruction Manual
7
Specifications and Features
Enclosure Models
BB-1001: Backbox for one annunciator chassis with keylock door.
BB-1002: Backbox for up to two annunciator chassis with keylock door.
BB-1003: Backbox for up to three annunciator chassis with keylock door.
BB-1008: Backbox for up to eight annunciator chassis with keylock door.
BB-1012: Backbox for up to twelve annunciator chassis with keylock door.
Module Models
RAM-1032(TZ) Main Annunciator Chassis, 32 Display Points (TZ version has 32 extra
trouble displays)
• 20 to 39 VDC (filtered or full-wave-rectified)
• Sealed membrane-like buttons and LED indicators.
• Local Buzzer, Indicators (AC-On, Common Trouble, Remote Failure, Aux. Disconnect,
Acknowledge, General Alarm, Signal Silence, Test/Config Mode), and Controls (System Reset,
Lamp Test, Fire Drill, Aux. Disconnect, Buzzer Silence, Signal Silence, General Alarm,
Acknowledge).
• Buzzer silence activation silences the main fire alarm panel buzzer and all attached
annunciator buzzers.
• Annunciation of up to 32 points (with trouble annunciation on the TZ version).
• Expandable by using up to four RAX modules.
• Standby: 50 mA Max., All LEDs “On”: 150 mA Max.
• TZ version: Standby 50mA Max., All LEDs “On”: 300mA Max.
RAM-1016(TZ) Main Annunciator Chassis, 16 Display Points (TZ version has 16 extra
trouble displays)
• 20 to 39 VDC (filtered or full-wave-rectified)
• Sealed membrane-like buttons and LED indicators.
• Local Buzzer, Indicators (AC-On, Common Trouble, Remote Failure, Aux. Disconnect,
Acknowledge, General Alarm, Signal Silence, Test/Config Mode), and Controls (System Reset,
Lamp Test, Fire Drill, Aux. Disconnect, Buzzer Silence, Signal Silence, General Alarm,
Acknowledge).
• Buzzer silence activation silences the main fire alarm panel buzzer and all attached
annunciator buzzers.
• Annunciation of up to 16 points (with trouble annunciation on the TZ version).
• Non-expandable.
• Standby: 50 mA Max., All LEDs “On”: 75 mA Max.
• TZ version: Standby 50mA Max., All LED’s “On” 150 mA Max.
Notes:
1. Enclosure finish: painted semi-gloss off white.
2. Material: BB-1001, BB-1002, BB-1003 are 18 GA. (0.048") thick CRS except the
BB-1003 Door, which is 16 GA (0.060”). BB-1008, BB-1012 backboxes are 16 GA.
(0.060") thick CRS, Doors are 14 GA (0.075”).
3. See Installation Instructions on page 2 for enclosure dimensions.
