RA-1000 Remote Annunciator Wiring and Instruction Manual
5
For FX-2000 Panels
Set the annunciator “Address” (see the manual for the fire alarm control panel being used), as
follows in the table below:
Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5
33
ON OFF OFF OFF OFF
49
ON OFF OFF OFF ON
34
OFF ON OFF OFF OFF
50
OFFONOFFOFFON
35
ON ON OFF OFF OFF
51
ON ON OFF OFF ON
36
OFF OFF ON OFF OFF
52
OFF OFF ON OFF ON
37
ON OFF ON OFF OFF
53
ON OFF ON OFF ON
38
OFF ON ON OFF OFF
54
OFF ON ON OFF ON
39
ON ON ON OFF OFF
55
ON ON ON OFF ON
40
OFF OFF OFF ON OFF
56
OFF OFF OFF ON ON
41
ON OFF OFF ON OFF
57
ON OFF OFF ON ON
42
OFF ON OFF ON OFF
58
OFF ON OFF ON ON
43
ON ON OFF ON OFF
59
ON ON OFF ON ON
44
OFF OFF ON ON OFF
60
OFF OFF ON ON ON
45
ON OFF ON ON OFF
61
ONOFFONONON
46
OFFONONONOFF
62
OFFONONONON
47
ON ON ON ON OFF
63
ON ON ON ON ON
48
OFF OFF OFF OFF ON
