Page 30
All Units in a TAS-2000 System must operate at the same RS-485 Communication Speed!!
2008M NSL UNIT CONFIGURATION
Most of the 2008M NSL Units settings are actually set by the 2001 Lobby Unit Configuration. One item that is separately set is
the NSL Unit’s ID and RS-485 Communications Speed. These are set by the DIP Switches on the NSL Unit’s Controller
Board. There is an eight position DIP Switch numbered SW2 on the Board located just above the ON/OFF Switch SW1. The
individual switches are numbered 1 to 8 from the top to the bottom, and are marked as either ON-OFF, or Closed-Open. The
first five switches set the ID ...
2008M NSL Unit ID # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5
THIS ADDRESS IS NOT ALLOWED
AS NSL ID
0 is used for PC ID ON ON ON ON ON
1 OFF ON ON ON ON
2 ON OFF ON ON ON
3 OFFOFFONONON
4 ON ON OFF ON ON
5 OFF ON OFF ON ON
6ONOFFOFFONON
7 OFF OFF OFF ON ON
8 ONONONOFFON
9 OFF ON ON OFF ON
10 ON OFF ON OFF ON
11 OFF OFF ON OFF ON
12 ON ON OFF OFF ON
13 OFF ON OFF OFF ON
14 ON OFF OFF OFF ON
15 OFF OFF OFF OFF ON
16 ON ON ON ON OFF
17 OFFONONONOFF
18 ON OFF ON ON OFF
19 OFF OFF ON ON OFF
20 ON ON OFF ON OFF
21 OFF ON OFF ON OFF
22 ON OFF OFF ON OFF
23 OFF OFF OFF ON OFF
24 ON ON ON OFF OFF
25 OFF ON ON OFF OFF
26 ON OFF ON OFF OFF
27 OFF OFF ON OFF OFF
28 ON ON OFF OFF OFF
29 OFF ON OFF OFF OFF
30 ON OFF OFF OFF OFF
31 OFF OFF OFF OFF OFF
NOTE: DIP Switches 6 and Switch 7 are NOT used.
Every NSL Unit in a given TAS-2000 System requires a unique ID. These should be assigned starting from “1" and
going up. Unit IDs must not be duplicated. For example if there are two Lobby Units in a system and they have
been given address 1 and 2, then those addresses are not available for the NSL Units.
The remaining DIP Switch, Switch 8, defines the NSL Unit’s RS-485 Communications Speed. This Switch 8 is
left in the “OFF” position for 2400 Baud.
