Page 43
All Units in a TAS-2000 System must operate at the same RS-485 Communication Speed!!!
2008E ELEVATOR RESTRICTION UNIT CONFIGURATION
Most of the 2008E Elevator Restriction Units settings are actually set by the 2001 Lobby Unit Configuration. One item that is
separately set is the Elevator Restriction Unit’s ID and RS-485 Communications Speed. These are set by the DIP Switches on
the Elevator Restriction Unit’s Controller Board. There is an eight position DIP Switch labelled SW2 on the Board located just
above the On/Off Switch SW1. The individual switches are numbered 1 to 8 from the top to the bottom, and are marked as
either ON-OFF, or Closed-Open. The first five switches set the ID ...
2008E Elevator Unit ID # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5
THIS ADDRESS IS NOT ALLOWED
AS ELEVATOR ID
0 is used for PC ID ON ON ON ON ON
1 OFF ON ON ON ON
2 ON OFF ON ON ON
3 OFFOFFONONON
4 ON ON OFF ON ON
5 OFF ON OFF ON ON
6ONOFFOFFONON
7 OFF OFF OFF ON ON
8 ONONONOFFON
9 OFF ON ON OFF ON
10 ON OFF ON OFF ON
11 OFF OFF ON OFF ON
12 ON ON OFF OFF ON
13 OFF ON OFF OFF ON
14 ON OFF OFF OFF ON
15 OFF OFF OFF OFF ON
16 ON ON ON ON OFF
17 OFFONONONOFF
18 ON OFF ON ON OFF
19 OFF OFF ON ON OFF
20 ON ON OFF ON OFF
21 OFF ON OFF ON OFF
22 ON OFF OFF ON OFF
23 OFF OFF OFF ON OFF
24 ON ON ON OFF OFF
25 OFF ON ON OFF OFF
26 ON OFF ON OFF OFF
27 OFF OFF ON OFF OFF
28 ON ON OFF OFF OFF
29 OFF ON OFF OFF OFF
30 ON OFF OFF OFF OFF
31 OFF OFF OFF OFF OFF
NOTE: DIP Switches 6 and Switch 7 are NOT used.
Every Elevator Restriction Unit in a given TAS-2000 System requires a unique ID. Unit IDs must not be duplicated.
The remaining DIP Switch, Switch 8, defines the Elevator Restriction Unit’s RS-485 Communications Speed.
This Switch 8 is left in the “OFF” position for 2400 Baud.
