Operation Manual Specifications for S3000
3-1
3. SPECIFICATIONS FOR S3000
Generator
100 Vac
110 Vac
220 Vac
Input Voltage
90-110 Vac @ 50/60 Hz
100-130 Vac @ 50/60 Hz
200-260 Vac @ 50/60 Hz
Full Load Current
10 Amps
10 Amps
7.5 Amps
Fuse Rating
10 Amps (GDB10)*
10 Amps (GDB10)*
8 Amps (GDB8)*
Weight
14 lbs. (6.3Kg)
14 lbs. (6.3Kg)
16.5 lbs. (7.4Kg)
Dimensions
7.5"W x18.5"L x11.6"H
19cm x 47cm x 29.5cm
Output Voltage
1500 V rms (max.)
Output Frequency
20 KHz (nom.)
Convertor
Weight
2 lbs. (0.9 Kg)
Dimensions
8" L x 2.5" Dia.
(20.3cm x 6.4cm)
Materials
Aluminum
Standard Horn
Weight
0.5 lbs. (0.45Kg)
Dimensions
5" L x1.5" Dia.
(12.7cm x 3.8cm)
Materials
Titanium Alloy
Environmental
Pollution Degree
Two (2)
Installation Category
II
Temperature Limits
50
o
F to 110
o
F
(10
o
C to 43
o
C)
Barometric Pressure
Unlimited**
*
Only use IEC approved fuses, model GDB10 for 100V, 120V and GDB8 for 220V. Do NOT use “slow blow” fuses or fuses rated above the
amperage noted.
**
In a Vacuum area, additional cooling provisions may be needed.
ACCESSORIES
Use only accessories and probes listed in the Misonix catalog as suitable for operation with this equipment. Do
NOT
attempt to fabricate ultrasonic tooling or accessories as the use of improper equipment can damage the Sonicator
and void the warranty.
