MIT 160

13
Packaging Sizes and Weights
As it is seen in the following gure, the diaphragm pump is connected to pump xing board from its
stands via bolt and nut. Lean of the pump is prevented during transport.
Scaling With Metal Body Scaling With Plastic Body
H
I
G
F
F
A
C
E
D
H
I
225
A B C D E F G H I J
279 110 110 270 181 150 220 209 130 163
A B C D E F G H I J
340 112 112 262 188 147 225 210 140 152
Plastic BodyMetal Body
Pump Weight Package Weight Gross Weight
5.9 kg 0.6 kg 6.5 kg
Pump Weight Package Weight Gross Weight
4.4 kg 0.6 kg 5 kg
A B C
300 150 230
A B C
300 200 400
