16
MIT 1500 Technical Information
Packaging Sizes and Weights
As it is seen in the following gure, the diaphragm pump is connected to pump xing board from its
stands via bolt and nut. Lean of the pump is prevented during transport.
Scaling With Metal Body Scaling With Plastic Body
E
D
F
B
C
H
I
G
G
H
A
I
D
J
A B C D E F G H I J
356 146 146 274 191 220 293 312 130 220
A B C D E F G H I J
480 315 286 356 250 139 218 172 200 265
Plastic BodyMetal Body
Pump Weight Package Weight Gross Weight
9.41 kg 0.390 kg 10 kg
Pump Weight Package Weight Gross Weight
8.280 kg 0.72 kg 9 kg
A B C
280 260 400
A B C
280 320 520
A
B
C
A
B
C
