Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
1.2.5 Super IO: NS PC 97338VJG
High speed PC16550A compatible UART with receive/transmit 16 Bytes FIFO programmable serial baud rate generator
Multi-mode parallel port support including standard port, EPP/ECP (IEEE1284 compliant, 2 interrupt pins)
Plug and Play module
FDC, 100% IBM compatible, S/W & register compatible to 82077 with 16Bytes data FIFO
Support 3-Mode FDD
FIR/MIR/SIR/SHARP ASK for Infrared application.
COM2
IrDA 1.0/ IrDA 1.1/ SHARP ASK
Baud rate: max. 4Mb
Link distance: 0.01 to 1 m
Half angle : ±15°
Bit Error Rate (BER) : 10 -9
Peak wavelength : 0.85 - 0.90 µm
TQFP 100 pins
Standby mode: control by software
Default configuration :
IO address
IRQx DRQx
COM1 3F8-3FF 4 -
FIR/MIR/SI 278-27F 3 -
R/ SHARP
ASK
(COM2)
PIO 378-37F 7 -
FDD 3F0-3FF 6 2
