90
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
5. Pin Descriptions Of Major Components
5.2 SiS630S Slot 1/Socket 370 2D/3D Ultra-AGP™ Single Chipset
Host Bus Interface
Name Tolerance Power
Plane
Type
Attr
Description
CPUCLK
3.3V/5V MAIN I
Host Clock :
ADS#
1.5V MAIN I/O
GTL+
Address Strobe :
Address Strobe is driven by CPU to
indicate the start of a CPU bus cycle.
HREQ[4:0]#
1.5V MAIN I/O
GTL+
Request Command:
HREQ[4:0]# are used to define
each transaction type during the clock when ADS# is
asserted and the clock after ADS# is asserted.
BREQ0#
1.5V MAIN O
GTL+
Symmetric Agent Bus Request:
BREQ0# is driven
by the symmetric agent to request for the bus.
BNR#
1.5V MAIN I/O
GTL+
Block Next Request:
This signal can be driven
asserted by any bus agent to block further requests
being pipelined.
HLOCK#
1.5V MAIN I
GTL+
Host Lock :
CPU asserts HLOCK# to indicate the
current bus cycle is locked.
HIT#
1.5V MAIN I/O
GTL+
Keeping a Non-Modified Cache Line:
HITM#
1.5V MAIN I/O
GTL+
Hits a Modified Cache Line:
Hit Modified indicates
the snoop cycle hits a modified line in the L1 cache of
CPU.
DEFER#
1.5V MAIN O
GTL+
Defer Transaction Completion:
SiS630 will use this
signal to indicate a retry response to host bus
.
RS[2:0]#
1.5V MAIN O
GTL+
Response Status:
RS[2:0]# are driven by the response
agent to indicate the transaction response type. The
following shows the response type.
RS[2:0] Response
000 Idle State
100 Reserved
001 Retry
101 No data
010 Reserved
110 Implicit Write-back
011 Reserved
111 Normal Data
HTRDY#
1.5V MAIN I/O
GTL+
Target Ready:
During write cycles, response agent
will drive TRDY# to indicate the agent is ready to
accept data.
DRDY#
1.5V MAIN I/O
GTL+
Data Ready:
DRDY# is driven by the bus owner
whenever the data is valid on the bus.
DBSY#
1.5V MAIN I/O
GTL+
Data Bus Busy:
Whenever the data is not valid on the
bus with DRDY# is deserted, DBSY# is asserted to
hold the bus.
Name Tolerance Power
Plane
Type
Attr
Description
BPRI#
1.5V MAIN O
GTL+
Priority Agent Bus Request:
BPRI# is driven by the
priority agent that wants to request the bus.
BPRI# has higher priority than BREQ0# to access a bus.
CPURST#
1.5V MAIN O
GTL+
Host Bus Reset:
CPURST# is used to keep all the bus
agents in the same initial state before valid cycles issued.
HA[31:3]#
1.5V MAIN I/O
GTL+
Host Address Bus :
HD[63:0]#
1.5V MAIN I/O
GTL+
Host Data Bus :
FERR#
1.5V~5V MAIN I
Floating Point Error :
CPU will assert this signal upon a
floating point error occurring.
IGNE#
1.5V~5V MAIN OD
Ignore Numeric Error :
IGNE# is asserted to inform CPU
to ignore a numeric error.
Speed Trap for PII :
This pin will be forced to voltage
level according to the input value of MD41 or APC0h.4
during system reset period.
NMI
1.5V~5V MAIN OD
Non-Maskable Interrupt :
A rising edge on NMI will
trigger a non-maskable interrupt to CPU. Speed Trap for
PII : This pin will be forced to voltage level according to
the input value of MD44 or APC0h.7 during system reset
period.
INTR
1.5V~5V MAIN OD
Interrupt Request :
High-level voltage of this signal
indicates the CPU that there is outstanding interrupt(s)
needed to be serviced.
Speed Trap for PII :
This pin will be forced to voltage
level according to the input value of MD43 or APC0h.6
during system reset period.
CPUSLP#
1.5V~5V MAIN OD
CPU Sleep :
SiS630 can optionally assert CPUSLP# to
force the CPU into deep sleep mode when going to S2 state.
STPCLK#
1.5V~5V MAIN OD
Stop Clock :
STPCLK# will be asserted to inhibit or
throttle CPU activities upon a pre-defined power
management event occurs.
SMI#
1.5V~5V MAIN OD
System Management Interrupt :
SMI# will be asserted
when a pre-defined power management event occurs.
