9. SPARE PARTS LIST-1
Part Number Description Location(s)
442051200001 AC ADP T ASSY;19V/3.16A,DELTA
541667000031 AK;1-EN,BOX,7521 MTC CTO
541667000001 AK;EN,7521-UTILIT Y ONLY
441999900047 BATT ASSY OPTION;LI-ION,7521 ID2C
442670040002 BAT T ASSY;14.8V,3.6AH,LI,PAN,ID2 C,7521
298000000002 BATTERY HOLDER;FOR CR2032,BH-800.1K BT501
338530010005 BAT TERY;LI,3V/220MAH,CR2032
340670020005 BEZEL ASSY;DVD-ROM,PIONEER,7521P
221670040001 BOX;AK,7521
340669600048 BRACKET ASSY-4;I/O,TV-OUT,RACE
342670000003 BRACKET; LCD,UNIPAC,L,7521
342670000004 BRACKET; LCD,UNIPAC,R,7521
342669600014 BRACKET;CD-ROM,RACE
342666600002 BRACKET;HDD,TITAN
344670000005 BUTTON;T OUCH PAD,7521
421015560001 CABLE ASSY;PHONE LINE,6P2C,W/Z CORE
421015560001 CABLE ASSY;PHONE LINE,6P2C,W/Z CORE
332300000115 CABLE;FFC,FDD,6020
332669600002 CABLE;FFC,IQSB BD,CHARGER BD,REDSEA
332669600001 CABLE;FFC,TOUCHPAD,REDSEA
272075103501 CAP ;.01U ,50V ,20%,0603,X7R,SMT PC104,PC98,C290,PC10
2
272075103702 CAP ;.01U ,50V,+80-20%,0603,SMT C27,C32,C34,C590,C600,
272075103401 CAP ;.01U ,CR,50V ,10%,0603,X7R,SMT PC118,PC121,PC124,PC
1
272005103401 CAP ;.01U ,CR,50V,10%,0805,X7R C174
272072104702 CAP ;.1U ,16V,+80-20%,0603,SMT C1,C103,C122,C123,C12
9
Part Numbe r De s cription Location(s )
272073104501 CAP ;.1U ,25V,+80-20%,0603,Y5V,SMT C525,C540,C549,C559,C
5
272075104701 CAP ;.1U ,50V,+80-20%,0603,SMT C143,C149,C160,C165,C
1
272072104402 CAP ;.1U ,CR,16V,10%,0603,X7R,SMT C10,C501,C517,C527,C5
3
272002474401 CAP ;.47U ,CR,16V ,10%,0805,X7R,SMT C12
272030102401 CAP ;1000P,2KV,10%,1808,X7R,SMT C17
272075102701 CAP ;1000P,50V ,+/-20%,0603,X7R,SMT C126,C134,C14,C25,C27
2
272075102403 CAP ;1000P,CR,50V,10%,0603,X7R,SMT PC51,P C58,PC60,PC63,P
272075101701 CAP ;100P ,50V ,+ -10%,0603,NP O,SMT C100,C101,C133,C5,C50
3
272075101401 CAP ;100P ,50V ,10%,0603,COG,SMT C505
272075100701 CAP ;10P ,50V ,+-10%,0603,NPO,SMT C113,C114,C116,C117,C
1
272075100401 CAP;10P ,50V ,10%,0603,COG,SMT C106,C514,C671
272021106501 CAP ;10U ,10V ,20%,1210,X7R,SMT C506,C507,P C7,P C83,PC
272011106701 CAP ;10U ,10V,+80-20%,1206,Y5V,SMT C223,C243,C244,C624,C
6
272012106701 CAP ;10U ,16V ,+80-20%,1206,Y5U,SMT C109,C112,C121,C179,C
1
272022106701 CAP ;10U ,16V,+80-20%,1210,Y5V,SMT C226,C39
272023106501 CAP ;10U ,25V ,20%,1210,Y5U,SMT PC14,P C35,C255,PC108,
5
272431157504 CAP ;150U ,4V ,20%,7343,POSCAP,SMT PC70,C124,P C119,P C12
0
272431157505 CAP ;150U ,6.3V ,20%7343,POSCAP,SMT PC10
272001105403 CAP ;1U ,10%,10V ,0805,X7R,SMT C518,C519,C520,C526,C
5
272071105701 CAP ;1U ,CR,10V ,80-20%,0603,Y5V C195,C46,C537,C54,C57
1
272012105702 CAP ;1U ,CR,16V ,+80-20%,1206,Y5V C250,C263,C679
272013105501 CAP ;1U ,CR,25V ,+80-20%,1206,SMT PC18
272002105701 CAP ;1U ,CR,16V ,-20+80%,0805,Y5V,S C139,C146,P C510,PC97,
P
272002225701 CAP ;2.2U ,CR,16V ,+80-20%,0805,Y5V C55,C56
272012225702 CAP ;2.2U ,CR,16V ,+80-20%,1206,Y5V C147,C152,C37
