MiTAC 7521 PLUS/N - Page 136

135
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
9. SPARE PARTS LIST-2
Part Number Description Location(s)
272075222701 CAP ;2200P,50V ,+/-20%,0603,X7R,SMT C107
272075221302 CAP;220P ,50V ,5% ,0603,NPO,SMT C23,C31,PC76,PC77
272075220701 CAP ;22P ,50V ,+ -10%,0603,NP O,SMT C108,C128
272021226701 CAP ;22U ,10V,+80-20%,1210,Y5V,SMT C154,PC519
272041226501 CAP ;22U ,CR,10V ,20%,1812,X7R,SMT C547
272011475401 CAP ;4.7U ,10%,10V ,1206,X7R,SMT C175
272001475701 CAP ;4.7U ,CR,10V ,+80-20%,0805,Y5V, C184,C20,C227,C36,C12
5
272012475701 CAP ;4.7U ,CR,16V ,+80-20%,1206,Y5V C521,C522,C523,C528,C
5
272075471401 CAP ;470P ,50V,10%,0603,X7R,SMT PC116
272075470401 CAP;47P ,50V ,10%,0603,COG,SMT C150,C157,C158,C163,C
1
221670020009 CARTON;NON-BRAND,TW,7521
431670020003 CASE KIT;ID3C 7521P MTC
342665500008 CFM-SUYIN;S-STANDOFF,#4-40H4.8,NIW
273000111002 CHOKE COIL;120OHM/100MHZ,20% ,3216 L12,L15,L544,L545,L8
313000020248 CHOKE COIL;15UH,16.5T S,55130,TUBE PL502
273000500023 CHOKE COIL;1UH ,20% ,15A,3.5MM,SMT PL11
273000500034 CHOKE;10UH,3.5A,3.65mm,T HA02P63,SMT PL6,P L8
313000020148 CHOKE;15UH,D.7*16T/.2*32,55130,T UBE PL503
331720015023 CON;D,FM,15P,2.29,R/A,3 ROW,TITAN J506
331720025012 CON;D,FM,25P,2.77,R/A,T IT AN J505
331720009008 CON;D,MA,9P,2.775,R/A,TITAN J507
291000151204 CON;FPC/FFC,12P ,.5MM,R/A,SMT,REDSEA J515
291000152604 CON;FPC/FFC,26P,1MM,R/A,ELCO,SMT J5
291000023002 CON;HDR,FM,15P *2,0.8MM.H4.4,R/A,SMT J511
291000023201 CON;HDR,FM,16P*2,1.27MM,R/A,SMT J514
Part Numbe r De s cription Location(s )
291000010604 CON;HDR,FM,6P *1,1.25MM,ST,SMT J1
291000012011 CON;HDR,MA,10P*2,1.0MM,ST,SMT J2
331040060003 CON;HDR,MA,20P*3,.8MM,R/A,AMP J516
291000025006 CON;HDR,MA,25P*2,.8MM,R/A,SMT J512
291000011410 CON;HDR,MA,7P *2,1.27MM,ST,H3MM,SMT J3
291000251441 CON;IC CARD,FM,72P *2,.6MM,H3MM,SMT U506
331870004005 CON;MINI DIN,4P,R/A,W/GROUNDING,F6S J501
331870006013 CON;MINI DIN,6P,R/A,W/GROUND,73156 J502
291000810805 CON;PHONE JACK,8P ,H=12.59,R/A,RJ45,C100 J504
331910003020 CON;POWER JACK,3P ,D=2.5,MARLIN PJ501
331840010001 CON;STEREO JACK,10P ,W/SPDIF,R/A J510
331840005007 CON;STEREO JACK,5P,R/A,W9.1,LGY2313 J503,509
331000008026 CON;USB,FM,H=13.62,R/A,4P*2,72309-6220B J508
291000410201 CON;WFR,MA,2P,1.25,ST,SMT/MB J4
291000410301 CON;WFR,MA,3P,1.25,ST,SMT/MB J513
345669600065 CONDUCTIVE TAPE;MB,SDRAM,RACE
345669600053 CONDUCTIVE TAPE;P CMCIA,RACE
313000150093 CORE;LAN CORE,230OHM/100MHZ,LF-100
340670020009 COVER ASSY;CPU,7521P
340670000031 COVER ASSY;EASY STAR,ID3,CHAMP,7521
340670000015 COVER ASSY;LCD,ID2,CHAMP,7521
441670020003 COVER ASSY;M/B,14",ID3C 7521P MTC
344670000051 COVER HINGE;ID2,CHAMP,7521
344670000013 COVER;MODEM,7521
272625101401 CP;100P*4,8P,50V ,10% ,1206,NP O,SMT CA3,CA4,CA5,CA6
