MiTAC 7521 PLUS/N - Page 137

136
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
9. SPARE PARTS LIST-3
Part Number Description Location(s)
272625470401 CP;47P*4 ,8P ,50V ,10%,1206,NPO,SMT CA501,CA502,CA7,CA8,
C
345669600062 CUSHION;CPU-1,RACE
291006214411 DIMM SOCKET;144P,.8MM,AMP353870,SMT J6
288100032013 DIODE;BAS32L,VRRM75V,MELF,SOD-80 PD10,PD11,P D14,PD15,
P
288100701002 DIODE;BAV70LT1,70V,225MW,SOT-23 D502
288100099001 DIODE;BAV99,70V,450MA,SOT-23 D5,D6,D7,D9
288100056003 DIODE;BAW56,70V,215MA,SOT-23 D17
288100212001 DIODE;DAN212K,80V,SWITCH,SOT23 D18
288101004024 DIODE;EC10QS04,RECT,40V,1A,CHIP ,SMT PD7,PD8,P D1,PD2,P D20
288103104001 DIODE;EC31QS04-TE12L,40V,3A,SMT PD18,PD19,P D3,PD4,P D
288104148001 DIODE;RLS4148,200MA,500MW,MELF,SMT D1,D14,D16,D19,D501,
D
288100020001 DIODE;RLZ20C,ZENER,19.23V,5%,SMT PD506
288100024002 DIODE;RLZ24D,ZENER,23.63V,5%,SMT PD501
288100056001 DIODE;RLZ5.6B,ZENER,5.6V,5%,LL34 D505,D15,D20
288100056005 DIODE;UDZ5.6B,ZENER,5.6V,UMD2,SMT D2,D506
451670000102 DVD ME KIT;8X,DVD-K11,7521
523467000005 DVD ROM ASSY;8X,K11TA,7521
272601107506 EC;100U ,6.3V,M,9.3*3.6,-55~105'C C11,C24
312271006358 EC;100U,25V,RA,M,D6.3*7,SGX,SANYO PC503,PC508
312272205359 EC;22U ,20V,20%,RA,D6.3*5,OS-CON PC521
272603226505 EC;22U ,20V,M,SVP,6.6mm,OS-CON,SMT PC127
272601337502 EC;330u ,6.3V,M,10.1*4.6,-55~105'C C4
312270687161 EC;680U,6.3V,20%D10,FUJITSU-FPCAP PC512,PC513
227670000003 END CAP;AK BOX,7521
227670000004 END CAP;BAT TERY,7521
Part Numbe r De s cription Location(s )
227670000002 END CAP ;MANUAL,7521
227670000010 END CAP ;W/CARRING BAG,7521
481670000002 F/W ASSY;KBD CTRL,7521+ U14
481670000001 F/W ASSY;SYS/VGA BIOS,7521+ U28
523411442008 FD DRIVE;1.44M,3 MODE,D353G
523467002001 FDD ASSY;7521P ID3C MTC
273000610013 FERRITE ARRAY;120OHM100MHZ,3216,MAG FA1,FA10,FA11,FA2,FA3,
273000610014 FERRITE ARRAY;60OHM/100MHZ,3216,MAG RP58
273000150013 FERRITE CHIP;120OHM/100MHZ,2012,6A L532,L533,L56,PL1,PL5
0
273000150031 FERRITE CHIP;120OHM/100MHZ,2012,SMT L9,L2,L3,L4,L55,L6
273000130039 FERRITE CHIP;130OHM/100MHZ,1608,SMT L33,L36,L37,L38,L39,L4
0
273000150036 FERRITE CHIP;32OHM/100MHZ,2012,SMT C102,C16,L21,R10,R73
273000130006 FERRITE CHIP;600OHM/100MHZ,.2A,1608 L504,L511
273000130038 FERRITE CHIP;600OHM/100MHZ,1608,SMT L10,L11,L13,L16,L18,L2
3
273000150022 FERRITE CHIP;60OHM/100MHZ,2012,SMT L20,L5
346664900010 FILM;LCD PROTEC,.14.2",235*300,5027
288003600001 FIR;HSDL3600#007,FRONT VIEW,10P ,SMT U501
295000010008 FUSE;1.1A,P OLY SWIT CH,1812,SMT F1
295000010014 FUSE;1.1A/6V,P OLY SWIT CH,P TC,SMD F502,F503
295000010105 FUSE;1A,NORMAL,1206,SMT F2
295000010029 FUSE;FAST,.75A,63V,1206,THIN FILM PF1
295000010016 FUSE;NORMAL,6.5A/32VDC,3216,SMT PF501
345669600055 GASCKET;TV-OUT,RACE
345669600047 GASKET;FDD,LONG,RACE
345669600048 GASKET;FDD,SHORT,RACE
