2.2.3 Modem Card
Disassembly
1. Carefully put the notebook upside down.
2. Remove one screw locking the modem card compartment cover, and then lift the cover up. (figure 2-5)
Figure 2-5 Figure 2-6
3. Remove one screw fastening the connector board and the grounding cable. (figure 2-6)
