Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
5.1 Pentium III/Celeron FC-PGA2 CPU
5. Pin Descriptions Of Major Components
PWRGOOD Relationship at Power On
Signal Name I/O Signal Description
VID[4:0]
O -
Open-
drain
The VID[4:0] (Voltage ID) pins/balls can be used to support
automatic selection of power supply voltages. These pins/balls are not
signals, they are either an open circuit or a short to VSS on the
processor substrate. The combination of opens and shorts encodes the
voltage required by the processor. External to pull-ups are required to
sense the encoded VID. For processors that have Intel SpeedStep
technology enabled, VID[4:0] encode the voltage required in the
battery-optimized mode. VID[4:0] are needed to cleanly support
voltage specification changes on mobile Pentium III processors. The
voltage encoded by VID[4:0] is defined in Table 39. A "1" in this
table refers to an open pin/ball and a "0" refers to a short to VSS. The
power supply must provide the requested voltage or disable itself.
Please note that in order to implement VID on the BGA2 package,
some VID[4:0] balls may be depopulated. For the BGA2 package, a
"1" in Table 39 implies that the corresponding VID ball is
depopulated, while a "0" implies that the corresponding VID ball is
not depopulated.
But on the Micro-PGA2 package, VID[4:0] pins are not depopulated.
