30
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
1.2.12 Interface
Power Supply Jack.
One Standard Parallel Port With ECP/EPP Functions
Supports Two USB port for all USB devices.
Supports Macrovision’s TV-OUT connector.
Tunable volume by variable resistor.
Two Serial Ports, One For COM1/COM2, The Other For FIR/MIR/SIR/SHARP ASK.
One External CRT Connector For CRT Display.
One PS/2 Interface For External KB, Mouse Or Other Devices.
Two Cardbus Sockets.
Cable For Connection Between M/B And Panel.
Cable For Connection Between M/B And Backlight BD.
Digital (Optical, 48KHz) / Analog Line-out Jack, Line-In Jack and Microphone Input Jack.
One MODEM RJ-11 phone jack for PSTN line and RJ-45 for LAN.
Battery translation board connection between M/B and battery.
Easy start buttons translation board (ESB) connection between M/B and five Buttons.
Internet quick start button translation board (IQSB) connection between M/B and touch pad, three LEDs, Mail Received
Button Buttons.
FDD-HDD translation board connection between M/B and floppy, hard disk.
One CD-ROM connector on M/B.
