Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
1.2.14 IR MODULE: HSDL-3600#007
Fully Compliant to IrDA 1.1 Specifications
115.2 kb/s to 4 Mb/s operation
Excellent nose-to-nose operation
Compatible with ASK, HP-SIR, and TV Remote
IEC825-Class 1 Eye Safe
Wide Operating Voltage Range
2.7 V to 5.25 V
Small Module Size
4.0 x 12.2 x 5.1 mm (HxWxD)
Complete Shutdown
TXD, RXD, PIN diode
Low Shutdown Current
10 nA typical
Adjustable Optical Power Management
Adjustable LED drive-current to maintain link integrity
Single Rx Data Output
FIR Select pin switch to FIR
Integrated EMI Shield
Excellent noise immunity
Edge Detection Input
Prevents the LED from long turn-on time
Interface to various Super I/O and Controller Devices
Designed to Accommodate Light Loss with Cosmetic Window
Minimum External Components Required
