Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
Logic Tech: 904255-0002
Vcc: 5V +- 0.5
Icc (max): 15 mA
Interface: PS/2
X/Y position resolution: 480+-50 CPI
Dimension: 66mm x 50mm x 5.0mm
Effective area: 55mm x 39 mm
Operating Temp. : 0 - 50 degree C
Storage humidity: 5 - 90 %,
Storage Temp.: -20 - + 60 degree C
ESD: 15KV applied to front surface
Touch Pad
System has optional MATSUSHITA UJDA150 24X speed CD-ROM drive, LGS CRN8241B 24X speed CD-ROM
drive, or TEAC CD-224E-A92 24X speed CD-ROM drive.
Hardware interface is compliant with ATAPI IDE specification.
IDE second channel (170h). The default drive is D. User should install the CD-ROM device driver in order to
operate this device. This CD-ROM drive also support audio interface. Co-operate with audio circuit, CD-ROM
drive can work as a CD player.
Ejection: Manual eject using the eject button/Automatically eject using the tray
24X CD-ROM Drive
