46
7521
7521
Plus / N N/B MAINTENANCE
Plus / N N/B MAINTENANCE
Lower ICON LEDs on M/B
Mail Received status (left 1)
AC POWER (left2)
BATTERY POWER (right 2)
BATTERY STATUS (right 1)
Upper ICON LEDs on M/B
CD-ROM/MO (left 1)
HARD DISK DRIVE (left 2)
FLOPPY DISK DRIVE (left 3)
NUM LOCK (right 3)
CAPS LOCK (right 2)
SCROLL LOCK (right 1)
CMOS Battery
LED Indicators
HP HSDL-3600#007 FIR Module
Meet IrDA Physical Layer Specification
1 cm to 1 Meter Operating Distance
30 degree Viewing Angle
Support Two Channels - 2.4 Kb/s to 115.2Kb/s and 1.15Mb/s to 4.0 Mb/s
IO port
CR2032 3V 220mAh lithium battery
When AC in or system main battery in, CMOS battery will no power consumption.
AC or main battery not exists, CMOS battery life at less (220mAh/5.8uA) 4 years.
In normal condition, battery life is at less over 4 years. Battery was put in battery holder.
