5. Pin Descriptions Of Major Components
5.2 SiS630S Slot 1/Socket 370 2D/3D Ultra-AGP™ Single Chipset
USB interface
Name Tolerance Power
Plane
Type
Attr
Description
CLK48M
3.3V/5V MAIN I
USB 48 MHz clock input :
This signal provides
the fundamental clock for the USB Controller.
OC0#
PCIREQ3#
GPIO0
3.3V/5V MAIN I
I
I/O/OD
USB Port 0 Over Current Detection :
OC0# is
used to detect the over current condition of USB
Port 0.
External PCI Master Request 3:
PCIREQ3# is
used for PCI Device on PCI Slot 3 to assert its
request to hold PCI Bus.
General Purpose Input/Output 0 :
Refer to GPIO
description.
OC1#
PCIGNT3#
GPIO1
3.3V/5V MAIN I
O
I/O/OD
USB Port 1 Over Current Detection :
OC1# is
used to detect the over current condition of USB
Port 1.
External PCI Master Grant 3 :
PCIGNT3# is
used to indicate PCI Device on PCI Slot 3 the PCI
Bus has been granted.
General Purpose Input/Output 1 :
Refer to GPIO
description.
OC3#
LDRQ1#
GPIO2
3.3V/5V MAIN I
I
I/O/OD
USB Port 3 Over Current Detection:
OC3# is
used to detect the over current condition of USB
Port 3.
LPC DMA Request 1 :
LDRQ1# is the second
LPC DMA request signal used by LPC Device to
request DMA cycles.
General Purpose Input/Output 2 :
Refer to GPIO
description.
USBP[4:0]P
3.3V AUX I/O USB Port [4:0] Positive Input/Output
USBP[4:0]N
3.3V AUX I/O USB Port [4:0] Negative Input/Output
Power and Ground Signals
Name Tol e ranc e Powe r
Plane
Ty p e
At tr
De sc ri pt i o n
VSS
GROUND 0V
I VDD
MAI N 1 . 8 V
IVDD (AUX)
AUX 1. 8V
OVDD
(AUX)
AUX 3. 3V
USBVDD
AUX 3. 3V
RTCVDD
RT C 1 . 8 V
DCLKAVDD
MAI N 3 . 3 V
ECLKAVDD
MAI N 3 . 3 V
TXAVDD
AUX 3. 3V
RXAVDD
AUX 3. 3V
DACAVDD
MAI N 3 . 3 V
IDEAVDD
MAI N 1 . 8 V
SDAVDD
MAI N 3 . 3 V
CPUAVDD
MAI N 3 . 3 V
VTTB
MAI N 1 . 5 V
VSS Q
GROUND 0V
VTTA
MAI N 1 . 5 V
VCC3
MAI N 3 . 3 V
Legacy I/o and Miscellaneous Signals
Name Tolerance Power
Plane
Type
Attr
Description
SPK
3.3V MAIN O
Speaker output :
The SPK is connected to the
system speaker.
