By using the SENS LEVEL dip
-switches on the RX board , you can set the signal attenuation level.
Procedure:
1.
Enter the configuration mode (CNF in ON) and wait for the led to stop flashing.
2.
Program the two dip-switches following the combinations indicated in the following table:
3.
Exit the configuration mode by programming the CNF dip-switch in OFF mode, avoiding
interrupting the signal and moving the antenna.
RX board
- signal attenuation level setting
DIP 1 DIP 2
OFF OFF Minimal Sensitivity (-5db)
ON OFF (-3,8 db)
OFF ON (-2,5 db)
ON ON Maximum Sensitivity (-1,5db)
By using the SENS TIME dip
-switches on the RX board , it is possible to set the duration of the signal
attenuation.
Procedure:
1.
Enter the configuration mode (CNF in ON) and wait for the led to stop flashing.
2.
Program the two dip-switches following the combinations indicated in the following table:
3.
Exit the configuration mode by programming the CNF dip-switch in OFF mode, avoiding
interrupting the signal and moving the antenna.
RX board
- duration setting of signal attenuation
DIP 1 DIP 2
OFF OFF 50 mS
ON OFF 150 mS
OFF ON 250 mS
ON ON 350 mS
TX board
- 4dB transmission level attenuation setting
By using the SENS LEVEL dip
-switches on the TX board , the signal transmission level can be
attenuated by 4
dB.
Procedure:
1.
Enter the configuration mode (CNF in ON) and wait for the led to stop flashing.
2.
Program the two dip-switches in ON mode (the red led will switch off).
3.
Exit the configuration mode by programming the CNF dip-switch in OFF mode, avoiding
interrupting the signal and moving the antenna.
IMPORTANT
It is only possible to enter the configuration mode once to program the dip-switches.
In manual control mode it is not possible to make changes using the software.
