MITECH MICRO 8 - Components

MICRO 8
Installation and user manual
Page 4 of 24
Components
0
0 0
0
MITECH MW-E485
CLOSING CAP
POLYCARBONATE
COVER
MAIN SUPPORT BRACKET WITH CABLE PASSAGE PROTECTION
(ALSO USABLE WITH MICRO BOX AND MICRO PL ACCESSORIES)
COVER CAP SCREW
TAMPER
RX or TX
ANTENNA
RS485 MODULE
WITH BUZZER
BOX FOR WALL OR POLE
MOUNTING
CABLE GLAND
MICRO BOX MICRO PL
POLE MOUNTING
BRACKET
TO USE
WITH MICRO BOX
(Dimensions 100x100x50 mm)
