MITECH MICRO 8 - Mounting Options Pages from 5 to; Horizontal and Vertical Orientation

Horizontal
and vertical adjustment
Horizontal
adjustment
180°
HORIZONTAL ADJUSTMENT
Vertical
adjustment
It is possible to orient the antenna vertically by adjusting the four fixing screws up to a
maximum of 5
°.
MICRO 8
Installation and user manual
Page 9 of 24
FRONT VIEW SIDE VIEW 1 LATERAL VIEW 2
5° DOWNWARD
ADJUSTMENT
LATERAL VIEW 3
5° UPWARD
ADJUSTMENT
