33 R/G T E T1 E M
8 G/R R M R1 SG SB
34 R/BR T T E M T
9 BR/R R R M SB R
35 R/S T E T T T1
10 S/R R M R R R1
36 BK/BL T T T1 E E
11 BL/BK R R R1 SG SG
37 BK/O T E E M M
12 O/BK R M M SB SB
38 BK/G T T T T T
13 G/BK R R R R R
39 BK/BR T E T1 E T1
14 BR/BK R M R1 SG R1
40 BK/S T T E M E
15 S/BK R R M SB SG
41 Y/BL T E T T M
16 BL/Y R M R R SB
42 Y/O T T T1 E T
17 O/Y R R R1 SG R
43 Y/G T E E M T1
18 G/Y R M M SB R1
44 Y/BR T T T T E
19 BR/Y R R R R SG
45 Y/S T E T1 E M
20 S/Y R M R1 SG SB
46 V/BL T T E M T
21 BL/V R R M SB R
47 V/O T E T T T1
22 O/V R M R R R1
48 V/G T T T1 E E
23 G/V R R R1 SG SG
49 V/BR T E E M M
24 BR/V R M M SB SB
50 V/S -- -- SPARE -- --
25 S/V -- -- SPARE -- --
Pin
Color
Code
RJ21X RJ2EX RJ2GX RJ2FX RJ2HX
