Mitel 3300 ICP - Page 71

Specifications
Release 3.3 63
RS-232 Maintenance Connector Allocation
Signal Name RJ-45 Connector Pin
DTR (data terminal ready)
DCD (data carrier detector)
1
RXD (receive data) 2
TXD (transmit data) 3
DTR (data terminal ready) 4
GND 5
Not used 6
RTS (ready to send) 7
CTS (clear to send) 8
Not used 9
BRI Connector Allocation
T1 1
T2 2
T3 3
T4 4
T5 5
T6 6
T7 7
T8 8
T9 9
T10 10
T11 11
T12 12
T13 13
T14 14
T15 15
R1 26
R2 27
R3 28
R4 29
R5 30
R6 31
R7 32
R8 33
R9 34
R10 35
R11 36
R12 37
R13 38
R14 39
R15 40
