8
Element Function
t Programmable Personal
Keys and
Designation Card
Provides 24 keys that can be programmed as speed call keys,
feature keys, or line appearance keys, according to your
communication needs. Personal keys have status indicators.
On a 5224 or 5324 IP Phone, the bottom right personal key is
always your Prime Line key.
Write the name (speed call, feature or line appearance) of the
Personal keys that you program on the designation card (use
the side of the card with the textboxes provided).
Use the slot behind the plastic cover at the bottom of the phone to
remove/insert the designation card.
u Handsfree Speaker
Provides sound for handsfree calls and background music.
v Handset
Use for handset calls. If you are in headset or handsfree mode,
you do not need to use the handset.
Ring/Message Indicator
When indicator is…
it means that…
Flashing rapidly Your phone is ringing
Flashing slowly A Message or Callback Message is waiting at your phone
On Your phone is ringing another phone
Off Your phone is idle, or you are on a call
Selecting Menu Options
The 5224 and 5324 IP Phones have softkeys that allow you to select feature and menu
options.
About Feature Access Codes
Use of some features requires dialing access codes. The codes are flexible and may be
different than those in this guide. Ask your Administrator for a list of codes you should
use.
For Users on Resilient 3300 ICP Systems
If during a call, you hear two beeps that are repeated every 20 seconds it means that
your phone is switching to a secondary 3300 ICP system. The call continues but some of
