32/1531-ANF 901 43 Uen B2 2016-04-01
Installation Guide
Base Station
26
A.2 BS330 and BS340 proir to R4H
Table 2 Power consumption (watts) of base stations and cabling when powered from the PBX
Cable
length
(metres)
0.4 mm wire size
()
0.5 mm wire size
()
0.6 mm wire size
()
Without
EPP
With
EPP
Without
EPP
With
EPP
Without
EPP
With
EPP
0 5.0 5.0 5.0 5.0 5.0 5.0
100 5.2 5.1 5.1 5.1 5.1 5.1
200 5.3 5.3 5.2 5.2 5.1 5.1
300 5.6 5.5 5.3 5.3 5.2 5.1
400 5.8 5.7 5.5 5.4 5.3 5.2
500 6.1 5.9 5.6 5.5 5.4 5.2
600 6.5 6.2 5.8 5.6 5.4 5.3
700 - 6.6 6.0 5.8 5.5 5.3
800 - 7.1 6.2 5.9 5.6 5.4
900 - 7.9 6.5 6.1 5.7 5.4
1000 - - - 6.3 5.8 5.5
1100 - - - 6.6 5.9 5.6
1200 - - - 6.9 6.1 5.6
1300 - - - 7.3 6.2 5.7
1400 - - - 7.9 6.4 5.8
1500 - - - - 6.6 5.8
1600 - - - - 6.8 5.9
1700 - - - - 7.0 6.0
