Mitsubishi Electric EHSD-MEE - Page 39

39
Indoor unit switch setting display (Request code: 162 to 166)
0: OFF 1: ON
SW1, SW2, SW3, SW4, SW5
Display
1 2 3 4 5 6 7 8
0 0 0 0 0 0 0 0 00 00
1 0 0 0 0 0 0 0 00 01
0 1 0 0 0 0 0 0 00 02
1 1 0 0 0 0 0 0 00 03
0 0 1 0 0 0 0 0 00 04
1 0 1 0 0 0 0 0 00 05
0 1 1 0 0 0 0 0 00 06
1 1 1 0 0 0 0 0 00 07
0 0 0 1 0 0 0 0 00 08
1 0 0 1 0 0 0 0 00 09
0 1 0 1 0 0 0 0 00 0A
1 1 0 1 0 0 0 0 00 0B
0 0 1 1 0 0 0 0 00 0C
1 0 1 1 0 0 0 0 00 0D
0 1 1 1 0 0 0 0 00 0E
1 1 1 1 0 0 0 0 00 0F
0 0 0 0 1 0 0 0 00 10
1 0 0 0 1 0 0 0 00 11
0 1 0 0 1 0 0 0 00 12
1 1 0 0 1 0 0 0 00 13
0 0 1 0 1 0 0 0 00 14
1 0 1 0 1 0 0 0 00 15
0 1 1 0 1 0 0 0 00 16
1 1 1 0 1 0 0 0 00 17
0 0 0 1 1 0 0 0 00 18
1 0 0 1 1 0 0 0 00 19
0 1 0 1 1 0 0 0 00 1A
1 1 0 1 1 0 0 0 00 1B
0 0 1 1 1 0 0 0 00 1C
1 0 1 1 1 0 0 0 00 1D
0 1 1 1 1 0 0 0 00 1E
1 1 1 1 1 0 0 0 00 1F
0 0 0 0 0 1 0 0 00 20
1 0 0 0 0 1 0 0 00 21
0 1 0 0 0 1 0 0 00 22
1 1 0 0 0 1 0 0 00 23
0 0 1 0 0 1 0 0 00 24
1 0 1 0 0 1 0 0 00 25
0 1 1 0 0 1 0 0 00 26
1 1 1 0 0 1 0 0 00 27
0 0 0 1 0 1 0 0 00 28
1 0 0 1 0 1 0 0 00 29
0 1 0 1 0 1 0 0 00 2A
1 1 0
1 0 1 0 0 00 2B
0 0 1 1 0 1 0 0 00 2C
1 0 1 1 0 1 0 0 00 2D
0 1 1 1 0 1 0 0 00 2E
1 1 1 1 0 1 0 0 00 2F
0 0 0 0 1 1 0 0 00 30
1 0 0 0 1 1 0 0 00 31
0 1 0 0 1 1 0 0 00 32
1 1 0 0 1 1 0 0 00 33
0 0 1 0 1 1 0 0 00 34
1 0 1 0 1 1 0 0 00 35
0 1 1 0 1 1 0 0 00 36
1 1 1 0 1 1 0 0 00 37
0 0 0 1 1 1 0 0 00 38
1 0 0 1 1 1 0 0 00 39
0 1 0 1 1 1 0 0 00 3A
1 1 0 1 1 1 0 0 00 3B
0 0 1 1 1 1 0 0 00 3C
1 0 1 1 1 1 0 0 00 3D
0 1 1 1 1 1 0 0 00 3E
1 1 1 1 1 1 0 0 00 3F
0: OFF 1: ON
SW1, SW2, SW3, SW4, SW5
Display
1 2 3 4 5 6 7 8
0 0 0 0 0 0 1 0 00 40
1 0 0 0 0 0 1 0 00 41
0 1 0 0 0 0 1 0 00 42
1 1 0 0 0 0 1 0 00 43
0 0 1 0 0 0 1 0 00 44
1 0 1 0 0 0 1 0 00 45
0 1 1 0 0 0 1 0 00 46
1 1 1 0 0 0 1 0 00 47
0 0 0 1 0 0 1 0 00 48
1 0 0 1 0 0 1 0 00 49
0 1 0 1 0 0 1 0 00 4A
1 1 0 1 0 0 1 0 00 4B
0 0 1 1 0 0 1 0 00 4C
1 0 1 1 0 0 1 0 00 4D
0 1 1 1 0 0 1 0 00 4E
1 1 1 1 0 0 1 0 00 4F
0 0 0 0 1 0 1 0 00 50
1 0 0 0 1 0 1 0 00 51
0 1 0 0 1 0 1 0 00 52
1 1 0 0 1 0 1 0 00 53
0 0 1 0 1 0 1 0 00 54
1 0 1 0 1 0 1 0 00 55
0 1 1 0 1 0 1 0 00 56
1 1 1 0 1 0 1 0 00 57
0 0 0 1 1 0 1 0 00 58
1 0 0 1 1 0 1 0 00 59
0 1 0 1 1 0 1 0 00 5A
1 1 0 1 1 0 1 0 00 5B
0 0 1 1 1 0 1 0 00 5C
1 0 1 1 1 0 1 0 00 5D
0 1 1 1 1 0 1 0 00 5E
1 1 1 1 1 0 1 0 00 5F
0 0 0 0 0 1 1 0 00 60
1 0 0 0 0 1 1 0 00 61
0 1 0 0 0 1 1 0 00 62
1 1 0 0 0 1 1 0 00 63
0 0 1 0 0 1 1 0 00 64
1 0 1 0 0 1 1 0 00 65
0 1 1 0 0 1 1 0 00 66
1 1 1 0 0 1 1 0 00 67
0 0 0 1 0 1 1 0 00 68
1 0 0 1 0 1 1 0 00 69
0 1 0 1 0 1 1 0 00 6A
1 1 0
1 0 1 1 0 00 6B
0 0 1 1 0 1 1 0 00 6C
1 0 1 1 0 1 1 0 00 6D
0 1 1 1 0 1 1 0 00 6E
1 1 1 1 0 1 1 0 00 6F
0 0 0 0 1 1 1 0 00 70
1 0 0 0 1 1 1 0 00 71
0 1 0 0 1 1 1 0 00 72
1 1 0 0 1 1 1 0 00 73
0 0 1 0 1 1 1 0 00 74
1 0 1 0 1 1 1 0 00 75
0 1 1 0 1 1 1 0 00 76
1 1 1 0 1 1 1 0 00 77
0 0 0 1 1 1 1 0 00 78
1 0 0 1 1 1 1 0 00 79
0 1 0 1 1 1 1 0 00 7A
1 1 0 1 1 1 1 0 00 7B
0 0 1 1 1 1 1 0 00 7C
1 0 1 1 1 1 1 0 00 7D
0 1 1 1 1 1 1 0 00 7E
1 1 1 1 1 1 1 0 00 7F
OCH815A
