Mitsubishi Electric EHSD-MEE - Page 41

41
Output signal display (Request code: 175/553)
Please refer to Table 2 on relevant wiring diagram whilst using the following.
0: OFF 1: ON
OUT
Display
1 2 3 4 5A 5B 6 7
0 0 0 0 0 0 0 0 xx 00
1 0 0 0 0 0 0 0 xx 01
0 1 0 0 0 0 0 0 xx 02
1 1 0 0 0 0 0 0 xx 03
0 0 1 0 0 0 0 0 xx 04
1 0 1 0 0 0 0 0 xx 05
0 1 1 0 0 0 0 0 xx 06
1 1 1 0 0 0 0 0 xx 07
0 0 0 1 0 0 0 0 xx 08
1 0 0 1 0 0 0 0 xx 09
0 1 0 1 0 0 0 0 xx 0A
1 1 0 1 0 0 0 0 xx 0B
0 0 1 1 0 0 0 0 xx 0C
1 0 1 1 0 0 0 0 xx 0D
0 1 1 1 0 0 0 0 xx 0E
1 1 1 1 0 0 0 0 xx 0F
0 0 0 0 1 0 0 0 xx 10
1 0 0 0 1 0 0 0 xx 11
0 1 0 0 1 0 0 0 xx 12
1 1 0 0 1 0 0 0 xx 13
0 0 1 0 1 0 0 0 xx 14
1 0 1 0 1 0 0 0 xx 15
0 1 1 0 1 0 0 0 xx 16
1 1 1 0 1 0 0 0 xx 17
0 0 0 1 1 0 0 0 xx 18
1 0 0 1 1 0 0 0 xx 19
0 1 0 1 1 0 0 0 xx 1A
1 1 0 1 1 0 0 0 xx 1B
0 0 1 1 1 0 0 0 xx 1C
1 0 1 1 1 0 0 0 xx 1D
0 1 1 1 1 0 0 0 xx 1E
1 1 1 1 1 0 0 0 xx 1F
0 0 0 0 0 1 0 0 xx 20
1 0 0 0 0 1 0 0 xx 21
0 1 0 0 0 1 0 0 xx 22
1 1 0 0 0 1 0 0 xx 23
0 0 1 0 0 1 0 0 xx 24
1 0 1 0 0 1 0 0 xx 25
0 1 1 0 0 1 0 0 xx 26
1 1 1 0 0 1 0 0 xx 27
0 0 0 1 0 1 0 0 xx 28
1 0 0 1 0 1 0 0 xx 29
0 1 0 1 0 1 0 0 xx 2A
1 1 0
1 0 1 0 0 xx 2B
0 0 1 1 0 1 0 0 xx 2C
1 0 1 1 0 1 0 0 xx 2D
0 1 1 1 0 1 0 0 xx 2E
1 1 1 1 0 1 0 0 xx 2F
0 0 0 0 1 1 0 0 xx 30
1 0 0 0 1 1 0 0 xx 31
0 1 0 0 1 1 0 0 xx 32
1 1 0 0 1 1 0 0 xx 33
0 0 1 0 1 1 0 0 xx 34
1 0 1 0 1 1 0 0 xx 35
0 1 1 0 1 1 0 0 xx 36
1 1 1 0 1 1 0 0 xx 37
0 0 0 1 1 1 0 0 xx 38
1 0 0 1 1 1 0 0 xx 39
0 1 0 1 1 1 0 0 xx 3A
1 1 0 1 1 1 0 0 xx 3B
0 0 1 1 1 1 0 0 xx 3C
1 0 1 1 1 1 0 0 xx 3D
0 1 1 1 1 1 0 0 xx 3E
1 1 1 1 1 1 0 0 xx 3F
0: OFF 1: ON
OUT
Display
1 2 3 4 5A 5B 6 7
0 0 0 0 0 0 1 0 xx 40
1 0 0 0 0 0 1 0 xx 41
0 1 0 0 0 0 1 0 xx 42
1 1 0 0 0 0 1 0 xx 43
0 0 1 0 0 0 1 0 xx 44
1 0 1 0 0 0 1 0 xx 45
0 1 1 0 0 0 1 0 xx 46
1 1 1 0 0 0 1 0 xx 47
0 0 0 1 0 0 1 0 xx 48
1 0 0 1 0 0 1 0 xx 49
0 1 0 1 0 0 1 0 xx 4A
1 1 0 1 0 0 1 0 xx 4B
0 0 1 1 0 0 1 0 xx 4C
1 0 1 1 0 0 1 0 xx 4D
0 1 1 1 0 0 1 0 xx 4E
1 1 1 1 0 0 1 0 xx 4F
0 0 0 0 1 0 1 0 xx 50
1 0 0 0 1 0 1 0 xx 51
0 1 0 0 1 0 1 0 xx 52
1 1 0 0 1 0 1 0 xx 53
0 0 1 0 1 0 1 0 xx 54
1 0 1 0 1 0 1 0 xx 55
0 1 1 0 1 0 1 0 xx 56
1 1 1 0 1 0 1 0 xx 57
0 0 0 1 1 0 1 0 xx 58
1 0 0 1 1 0 1 0 xx 59
0 1 0 1 1 0 1 0 xx 5A
1 1 0 1 1 0 1 0 xx 5B
0 0 1 1 1 0 1 0 xx 5C
1 0 1 1 1 0 1 0 xx 5D
0 1 1 1 1 0 1 0 xx 5E
1 1 1 1 1 0 1 0 xx 5F
0 0 0 0 0 1 1 0 xx 60
1 0 0 0 0 1 1 0 xx 61
0 1 0 0 0 1 1 0 xx 62
1 1 0 0 0 1 1 0 xx 63
0 0 1 0 0 1 1 0 xx 64
1 0 1 0 0 1 1 0 xx 65
0 1 1 0 0 1 1 0 xx 66
1 1 1 0 0 1 1 0 xx 67
0 0 0 1 0 1 1 0 xx 68
1 0 0 1 0 1 1 0 xx 69
0 1 0 1 0 1 1 0 xx 6A
1 1 0
1 0 1 1 0 xx 6B
0 0 1 1 0 1 1 0 xx 6C
1 0 1 1 0 1 1 0 xx 6D
0 1 1 1 0 1 1 0 xx 6E
1 1 1 1 0 1 1 0 xx 6F
0 0 0 0 1 1 1 0 xx 70
1 0 0 0 1 1 1 0 xx 71
0 1 0 0 1 1 1 0 xx 72
1 1 0 0 1 1 1 0 xx 73
0 0 1 0 1 1 1 0 xx 74
1 0 1 0 1 1 1 0 xx 75
0 1 1 0 1 1 1 0 xx 76
1 1 1 0 1 1 1 0 xx 77
0 0 0 1 1 1 1 0 xx 78
1 0 0 1 1 1 1 0 xx 79
0 1 0 1 1 1 1 0 xx 7A
1 1 0 1 1 1 1 0 xx 7B
0 0 1 1 1 1 1 0 xx 7C
1 0 1 1 1 1 1 0 xx 7D
0 1 1 1 1 1 1 0 xx 7E
1 1 1 1 1 1 1 0 xx 7F
OCH815A
