Output signal display (Request code: 175/553)
Please refer to Table 2 on relevant wiring diagram whilst using the following.
Mixing valve 2 state
OUT
Mixing valve 2 state
5A 5B
0 0 Stop
0 1 Stop
1 0 Open
1 1 Close
0: OFF 1: ON
OUT
Display
8 * 9 10 11 12 13 14 15
0 0 0 0 0 0 0 0 00 xx
1 0 0 0 0 0 0 0 01 xx
0 1 0 0 0 0 0 0 02 xx
1 1 0 0 0 0 0 0 03 xx
0 0 1 0 0 0 0 0 04 xx
1 0 1 0 0 0 0 0 05 xx
0 1 1 0 0 0 0 0 06 xx
1 1 1 0 0 0 0 0 07 xx
0 0 0 1 0 0 0 0 08 xx
1 0 0 1 0 0 0 0 09 xx
0 1 0 1 0 0 0 0 0A xx
1 1 0 1 0 0 0 0 0B xx
0 0 1 1 0 0 0 0 0C xx
1 0 1 1 0 0 0 0 0D xx
0 1 1 1 0 0 0 0 0E xx
1 1 1 1 0 0 0 0 0F xx
0 0 0 0 1 0 0 0 10 xx
1 0 0 0 1 0 0 0 11 xx
0 1 0 0 1 0 0 0 12 xx
1 1 0 0 1 0 0 0 13 xx
0 0 1 0 1 0 0 0 14 xx
1 0 1 0 1 0 0 0 15 xx
0 1 1 0 1 0 0 0 16 xx
1 1 1 0 1 0 0 0 17 xx
0 0 0 1 1 0 0 0 18 xx
1 0 0 1 1 0 0 0 19 xx
0 1 0 1 1 0 0 0 1A xx
1 1 0 1 1 0 0 0 1B xx
0 0 1 1 1 0 0 0 1C xx
1 0 1 1 1 0 0 0 1D xx
0 1 1 1 1 0 0 0 1E xx
1 1 1 1 1 0 0 0 1F xx
0 0 0 0 0 1 0 0 20 xx
1 0 0 0 0 1 0 0 21 xx
0 1 0 0 0 1 0 0 22 xx
1 1 0 0 0 1 0 0 23 xx
0 0 1 0 0 1 0 0 24 xx
1 0 1 0 0 1 0 0 25 xx
0 1 1 0 0 1 0 0 26 xx
1 1 1 0 0 1 0 0 27 xx
0 0 0 1 0 1 0 0 28 xx
1 0 0 1 0 1 0 0 29 xx
0 1 0 1 0 1 0 0 2A xx
1 1 0
1 0 1 0 0 2B xx
0 0 1 1 0 1 0 0 2C xx
1 0 1 1 0 1 0 0 2D xx
0 1 1 1 0 1 0 0 2E xx
1 1 1 1 0 1 0 0 2F xx
0 0 0 0 1 1 0 0 30 xx
1 0 0 0 1 1 0 0 31 xx
0 1 0 0 1 1 0 0 32 xx
1 1 0 0 1 1 0 0 33 xx
0 0 1 0 1 1 0 0 34 xx
1 0 1 0 1 1 0 0 35 xx
0 1 1 0 1 1 0 0 36 xx
1 1 1 0 1 1 0 0 37 xx
0 0 0 1 1 1 0 0 38 xx
1 0 0 1 1 1 0 0 39 xx
0 1 0 1 1 1 0 0 3A xx
1 1 0 1 1 1 0 0 3B xx
0 0 1 1 1 1 0 0 3C xx
1 0 1 1 1 1 0 0 3D xx
0 1 1 1 1 1 0 0 3E xx
1 1 1 1 1 1 0 0 3F xx
* Displayed only when the request code is 553.
OUT
Display
8 9 10 11 12 13 14 15
0 0 0 0 0 0 1 0 40 xx
1 0 0 0 0 0 1 0 41 xx
0 1 0 0 0 0 1 0 42 xx
1 1 0 0 0 0 1 0 43 xx
0 0 1 0 0 0 1 0 44 xx
1 0 1 0 0 0 1 0 45 xx
0 1 1 0 0 0 1 0 46 xx
1 1 1 0 0 0 1 0 47 xx
0 0 0 1 0 0 1 0 48 xx
1 0 0 1 0 0 1 0 49 xx
0 1 0 1 0 0 1 0 4A xx
1 1 0 1 0 0 1 0 4B xx
0 0 1 1 0 0 1 0 4C xx
1 0 1 1 0 0 1 0 4D xx
0 1 1 1 0 0 1 0 4E xx
1 1 1 1 0 0 1 0 4F xx
0 0 0 0 1 0 1 0 50 xx
1 0 0 0 1 0 1 0 51 xx
0 1 0 0 1 0 1 0 52 xx
1 1 0 0 1 0 1 0 53 xx
0 0 1 0 1 0 1 0 54 xx
1 0 1 0 1 0 1 0 55 xx
0 1 1 0 1 0 1 0 56 xx
1 1 1 0 1 0 1 0 57 xx
0 0 0 1 1 0 1 0 58 xx
1 0 0 1 1 0 1 0 59 xx
0 1 0 1 1 0 1 0 5A xx
1 1 0 1 1 0 1 0 5B xx
0 0 1 1 1 0 1 0 5C xx
1 0 1 1 1 0 1 0 5D xx
0 1 1 1 1 0 1 0 5E xx
1 1 1 1 1 0 1 0 5F xx
0 0 0 0 0 1 1 0 60 xx
1 0 0 0 0 1 1 0 61 xx
0 1 0 0 0 1 1 0 62 xx
1 1 0 0 0 1 1 0 63 xx
0 0 1 0 0 1 1 0 64 xx
1 0 1 0 0 1 1 0 65 xx
0 1 1 0 0 1 1 0 66 xx
1 1 1 0 0 1 1 0 67 xx
0 0 0 1 0 1 1 0 68 xx
1 0 0 1 0 1 1 0 69 xx
0 1 0 1 0 1 1 0 6A xx
1 1 0
1 0 1 1 0 6B xx
0 0 1 1 0 1 1 0 6C xx
1 0 1 1 0 1 1 0 6D xx
0 1 1 1 0 1 1 0 6E xx
1 1 1 1 0 1 1 0 6F xx
0 0 0 0 1 1 1 0 70 xx
1 0 0 0 1 1 1 0 71 xx
0 1 0 0 1 1 1 0 72 xx
1 1 0 0 1 1 1 0 73 xx
0 0 1 0 1 1 1 0 74 xx
1 0 1 0 1 1 1 0 75 xx
0 1 1 0 1 1 1 0 76 xx
1 1 1 0 1 1 1 0 77 xx
0 0 0 1 1 1 1 0 78 xx
1 0 0 1 1 1 1 0 79 xx
0 1 0 1 1 1 1 0 7A xx
1 1 0 1 1 1 1 0 7B xx
0 0 1 1 1 1 1 0 7C xx
1 0 1 1 1 1 1 0 7D xx
0 1 1 1 1 1 1 0 7E xx
1 1 1 1 1 1 1 0 7F xx
OCH815A
