Outline dimension drawings
8.3 Outline dimension drawings
• Three-phase 200V class
• Three-phase 400V class
(Unit:mm)
Inverter model W W1 H H1 D
FR-E720-0.1KNF
68 56
128 118
89.5
FR-E720-0.2KNF
FR-E720-0.4KNF
121.5
FR-E720-0.75KNF
141.5
FR-E720-1.5KNF
108 96 144.5
FR-E720-2.2KNF
FR-E720-3.7KNF
170 158 151.5
FR-E720-5.5KNF
180 164
260 244
174
FR-E720-7.5KNF
FR-E720-11KNF
220 195 199
FR-E720-15KNF
Inverter model W W1 H H1 D
FR-E740-0.4KNF
140 128
150 138
123
FR-E740-0.75KNF
FR-E740-1.5KNF
144
FR-E740-2.2KNF
FR-E740-3.7KNF
FR-E740-5.5KNF
220
208 156
FR-E740-7.5KNF
FR-E740-11KNF
195 260 244 199
FR-E740-15KNF
D
W1
W
H1
H
