WINDOW GLASS REGULATOR
wire winding system is used in the window glass
regulator. Power windows which use a wire winding
system in the window glass regulator are equipped on
all models. Furthermore, the amount of lateral
movement of the window glass regulator carrier plate
is increased so the lateral deflection of the glass
which happens when opening and closing the com-
plex curved glass door window can be absorbed. In
Door window glass
order to prevent the glass from getting scratched, a
glass striker is mounted on the outside of the door
glass so the beltline weather-strip outer stabilizer is
only effective when the window is fully closed. When
the window is fully closed, the glass striker is inserted
between the outer stabilizer and door glass and firmly
presses the door glass.
Carrier plate
Door window
regulator assembly
4-12 BODY - Doors
