0-18
GENERAL - Major Specifications
MAJOR SPECIFICATIONS
F0015
Items Z16AMNGFL6 Z16AMNGFL Z16AMNGFLW
, Z16AMNGFR6 Z16AMNGFR Z16AMNGFR8
Dimensions mm(in.)
Overall length 1 4,560 (179.5)
Overall width 2 1,840 (72.4)
Overall height (unladen) 3 1,285 (50.6)
Wheelbase 4 2,470 (97.2)
Track-Front 5 1,560 (61.4)
Track-Rear 6 1,580 (62.2)
Ground clearance (unladen) 7 145 (5.7)
Overhang-Front 8 1,030 (40.6)
Overhang-Rear 9 1,060 (41.7)
Angle of approach degrees 10 11.2°
Angle of departure degrees 11 17.3°
Weight kg (Ibs.)
Kerb weight 1,740 (3,836)
/
Gross vehicle weight 2,120 (4,674)
Max. axle weight
Front 1,150 (2,535)
Rear 1,020 (2,249)
Seating capacity 4
Engine
Model 6G72
Total displacement cm
3
(cu.in) 2,972 (181.4)
Transmission
Model W5MG1
Type 5-speed manual
