151
WT07627X03
7-1-5. Blocks
By making block settings, multiple groups in a given block can be collectively monitored or operated on the Web
browser. Click [Initial Settings] in the menu bar, and then click [Blocks] to access the block settings screen. Register
the groups to each block, and then click [Save Settings].
Note: Some settings may not be accessible if logged in as a building manager.
Note: The groups of units connected to the AE-200, AE-50, and EW-50, as well as the groups of units connected to different
AE-50/EW-50 controllers, cannot be registered to the same block.
Note: The ventilation will stop when the Peak Cut control runs for the LOSSNAY units or OA Processing units that perform Night
purge operation. For this reason, do not register the LOSSNAY units and OA Processing units that perform Night purge
operation to the same block.
(1) Enter the block name in the [Block Name] field in 20 characters or less.
Note: The following characters cannot be used in the [Block Name] field: <, >, &, “, or ‘
(2) Click the [Group registration] field next to the target block. The [Select
Groups] screen will appear.
Select the group numbers to be registered. (To show the group name,
move the cursor to the group number.)
The selected group numbers will appear with a yellow-green
background.
Click again to deselect. The deselected group numbers will appear
with a light-gray background.
Note: HWHP (CAHV, CRHV, QAHV) unit groups and chiller unit groups cannot
be registered to a block.
Block Name
Refresh
Click to import the settings
from AE-200/AE-50/EW-50.
Group registration
Save Settings
Click to save the changes
made.
