91
WT07627X03
6-2. General descriptions of Initial Setting Tool
This section explains operation methods that are common to all setting screens of Initial Setting Tool.
6-2-1. Starting up the Initial Setting Tool
AE-200 Initial Setting Tool
The screen below will appear when the Initial Setting Tool is started up.
When [New] is clicked, all the settings in an unset status will be displayed.
When [Open] is clicked, the “Open” screen will be displayed. You can then select and load the settings file saved on
the PC (filename.dat) which has been created beforehand. Once the settings file are loaded, the settings screen will
be displayed with the settings in the file applied.
Note: When [Open] is clicked, the “Library” > “Documents” folder will be selected for the first time. Select the file saved on the
Initial Setting Tool.
Open
Click to open the existing
settings file
New
Click to newly create a
settings file.
To Next Page
