Towing bar mounting specifi-
cations
See the following table for fixing points (A)
for the towing bar.
1 830.5 mm
2 461 mm
3 68.5 mm
4 75 mm
5 310 mm
6 13.5 mm
7 66.5 mm
8 50 mm
9 52 mm
10
464 mm to 476 mm
464 mm to 479 mm*
(at kerb weight con-
dition)
10
375 mm to 401 mm
378 mm to 396 mm*
(at laden condition)
11 447 mm
12 487 mm
13 495 mm
14 525.5 mm
*: Vehicles for Russia, Kazakhstan and Uk-
raine
NOTE
l
The values under item 12 can be varied de-
pending on the loading condition of cargo or
luggage.
Operating hints
l
To prevent the clutch from slipping (Ve-
hicle with a M/T only), do not rev the
engine more than is required when start-
ing off.
l
Be sure that the driving speed does not
exceed 100 km/h (62 mph) for trailer op-
eration. It is also recommended that you
obey the local regulations in case driving
speed with a trailer is limited to less than
100 km/h (62 mph).
l
To prevent shocks from the overrun
brake, depress the brake pedal lightly at
first and then more strongly.
Trailer towing
6-73
OGAE15E5
Starting and driving
6
