Reversing lamps
E01004401430
1. Open the tailgate.
2. Insert a straight blade (or minus) screw-
driver into the notch of the cover and pry
gently to remove the cover.
NOTE
l
Wrap a piece of cloth around the tip of the
screwdriver in order to avoid scratching the
cover.
3. Remove the socket and bulb assembly
by turning it anticlockwise.
4. Remove the bulb by pulling it out.
5. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lid, align the tab on the
lid with the hole on the vehicle side.
Replacement of lamp bulbs
10-36
OGAE15E5
Maintenance
10
