Mitsubishi ASX 2016

To remove
1. Remove the clips (A), and then remove
the upper cover (B).
2.
Remove the clips (C), and then remove
the air duct (D).
To install
1. Install the air duct (A), and then tighten
the clips (B).
2.
Turn the upper cover over. Squeeze the
head of the moulding clip (C) with pliers
and remove the moulding.
3. Install the upper cover, and then attach
the moulding (D).
NOTE
l
Attach the moulding with the wide part to-
wards the front of the vehicle.
4. Install the clips (E).
Battery
10-11
OGAE15E5
Maintenance
10
