Mitsubishi ASX 2016

2
1
16
15
14
13
12
11
10
9
8
7
5
6
3
4
RHD
1. Instruments p. 5-02
2. Combination headlamps and dipper switch p. 5-48
Turn-signal lever p. 5-55
Front fog lamp switch* p. 5-56
Rear fog lamp switch p. 5-56
Headlamp washer switch* p. 5-62
3. Auto Stop & Go (AS&G) OFF switch* p. 6-22
4. Headlamp levelling switch* p. 5-54
5. Active stability control (ASC) OFF switch* p. 6-52
6. Sonar switch* p. 6-66
7. Cruise control switch* p. 6-54
8. Supplemental restraint system - airbag (for driver’s seat) p. 4-24,
4-29
Horn switch p. 5-63
9. Ignition switch* p. 6-12
10. Supplemental restraint system - driver’s knee airbag* p. 4-29
11. Bluetooth® 2.0 interface* p. 7-48
12. Steering wheel audio remote control switches* p. 7-24
13. Tilt & Telescopic steering lever p. 6-08
14. Engine switch* p. 3-13
15. Windscreen wiper and washer switch p. 5-57
Rear window wiper and washer switch p. 5-61
16. Shift paddles* p. 6-36
Instruments and controls
1-03
OGAE15E5
Overview
1
