Location of each cameras
The cameras are integrated into the location
as shown below.
A- Rear-view camera
B- Front-view camera
C- Side-view camera
WARNING
l
Do not install anything which will disturb
the operation of the cameras around the
location of them.
Range of view of the Multi
Around Monitor
E00645100223
The range of view of the Multi Around Mon-
itor cameras is limited to the area shown in
the illustrations. It cannot show around the
both sides and the lower part of the front and
rear bumpers, etc. While driving, be sure to
visually confirm safety around the vehicle.
Range of view of the Multi
Around Monitor cameras
Multi Around Monitor*
6-117
OGKE18E1
Starting and driving
6
