Cargo area cover*
E00733601199
To use
1. Draw out the cover retracted by spring
and insert it in the mounting grooves
(A).
2. Remove the cover from the mounting
grooves, and the cover will roll back into
the retracted position.
NOTE
l
Do not put luggage on the cover.
To change position
There are two installation holes (B) for the
cover.
1. Move one of the sliders (C) towards the
inside of the vehicle, and fit the tab (D)
into the installation hole that is to be
used. Move the opposite slider in the
same fashion.
2. After changing the position, gently
shake the entire cover to make sure it is
securely retained.
NOTE
l
If the rear seatback touches the cover, move
the cover rearward.
The cover could break if it supports the seat-
back of the rear seat.
To remove
1. Roll the cover into the retracted position.
2. Move one of the sliders (C) towards the
inside of the vehicle and lift it to remove
the cover.
Cargo area cover*
7-88
OGKE18E1
For pleasant driving
7
